C4 - 4Runner Lo Pro Winch Bumper / 5th Gen / 2014+

SKU 91047
$749.70
Built to Order
was $882.00
Save $132.30
Model
LED Cutout Option
Bull Bar Option
LED Lightbar
LED Bar Wiring Harness
Winch
Add Warn Control Pack Relocation Kit
Hawse License Plate Mount
Shipping Options
Out of stock at our main facility, available for back-order and may ship from alternate warehouse or from the manufacturer
1
Product Details
Made in: USA
Brand: C4 Fabrication
Vehicle: 4Runner
Lead Time (Contact us if you have questions): ships within 6-8 weeks typically
Shipping Notes: this item is made to order and will ship from the manufacturer, we may have some in stock for pickup at Apex Overland

C4 - 4Runner Lo Pro Winch Bumper / 5th Gen / 2014+

ALL BUMPERS NOW COME WITH THE “C4” LOGO CUT INTO THE LIGHT BAR CUTOUT AREA. The “C4” logo will still be cut in that location if “no cutout” is selected under light bar cutout options. “C4 Fab” will no longer be cut into the lower portion of the bumper as some of the photos show.
  • We have now verified that the Full Height Bull Bar DOES NOT interfere with TSS. The Mid height bull bar definitely will block the TSS sensor and cause a malfunction.
  • Can be ordered with or without cut outs for various LED bars (Extreme Led Light Bars, Baja Designs, Rigid)
  • Bumper is not guaranteed to fit different brand/sizes of single row LED lights.
  • CNC cut and press brake bent from 3/16″ P&O steel.
  • Fits all ’14 and up 4Runner’s except the Limited model.
  • Comes with all mounting brackets and hardware needed for install.
  • Product ships bare steel, we do not offer powder coating at this time for shipping orders. Contact APEX OVERLAND and we will coordinate powdercoating for installed parts.
  • Product will be shipped through FedEx ground home delivery or to a commercial address if one is provided.
  • Fits most winches 8k-12k in size. Winches with the ability to relocate the electrical control box are recommended. Integrated control box winches may require some trimming of the grille support brackets to fit.(ComeUp, Smittybilt X20, Warn Zeon and VR series are all common winches that fit).
  • Cutting of the center plastic portion of the factory bumper cover is required to install the bumper.
  • Weighs 75lbs
  • Works with TRD Pro Skid Plate
