Apex Overland ADVENTURER Package with Radflo Suspension | 23+ Sequoia & 22+ Tundra

The Apex Overland Stage 2 Packages (INCLUDES INSTALLATION) are designed for those needing a little more performance out of their vehicles in the hobby of overland and off-road and need a one stop shop for their:

2023+ Toyota Sequoia or 2022+ Toyota Tundra

Apex Overland also offers expert installation for all of our packages. For those not local to Apex Overland, we offer FREE SHIPPING to your door for our packages. Contact us for package discounts!

Our Stage 2 Systems will include the Radflo 2.5 Suspension system paired with Total Chaos Upper control arms, with optional add ons.

LEAD time varies on this package, so there maybe a wait on our next batch of incoming inventory, typically 3-4 weeks. Contact us before placing your order if you have any questions.

Packages Include:

• Radflo 2.5" Diameter Extended Travel Front Coilover Kit with Remote Reservoirs
  • All Radflo OE Replacement Shocks are custom built-to-order in the USA, and uniquely valved to meet you and your vehicle's unique needs and specifications.
  • Front Coilovers are adjustable from 0-2.5" of lift
  • Nitrogen charged design with internal floating piston to help prevent shock fading and cavitation.
  • Anodized Aluminum Material and Finish
  • Shocks are fully rebuildable and factory serviceable
  • The kit includes C-Spanner wrench adjustment tool.

Front Bump Stop Option

• DuroBumps are proudly made in the USA with dual durometer (hardness) rubber that provides smooth progressive dampening and greatly reduces hard bottom outs. This allows for more control and comfort compared to OEM bump stops that are harsh on contact. With DuroBumps installed, the shell-shock effect experienced when hitting the OEM bump stops is completely eliminated.
• Icon - micro-cellular foam material is more compliant and will help to soften bottom-outs when the suspension reaches full compression and provides improved performance over the OE bump stops with an easy bolt-on installation.

• Dobinsons 2-3" springs with different load ratings to meet your needs
  • C59-817V (25mm - 1") Stock Load
  • C59-819V (50mm - 2") Stock Load
  • C59-821V (75mm - 3") Stock Load / (50mm - 2") 220-440lb Load
  • C59-823V (75mm - 3") 220-440lb Load / (50mm - 2") 600-800lb Load
  • C59-851V (75mm - 3") Stock Load (True 3" for TRD PRO ONLY, Will overlift on non TRD PRO)
  • C59-853V (75mm - 3") 220-440lb Load (True 3" for TRD PRO ONLY, Will overlift on non TRD PRO)

Rear Shocks:

• Radflo 2.5" Diameter rear shocks with Internal Floating Piston with Remote Reservoirs
  • Shock bodies are hard-anodized aluminum for cooler operation and longer lasting in the elements.
  • Self Adjusting valving
  • Nitrogen charged

Upper Control Arms to complete your kit:

• Total Chaos
  • Urethane bushings reduce bushing deflection compared to stock rubber bushings.
  • CNC tapered spindle adapters convert the factory ball joint to a 1" uniball for added component strength & maximum wheel travel.
  • 4130 chromoly tubular upper control arms are 100% bolt on.
• Icon Tubular UCA DJ Pro Kit
• • Delta Joint PRO is 100% serviceable and rebuildable
  • Delta Joint PRO allows maximum articulation without binding

Lighting Options

CBI Ditch-light with CaliRaised side shooter pods Package with Install

Additional Options

Factor 55 Hitchlink 2.0
Maxtrax (Color options vary)
